Kyn61 40.5 MV 33kv Indoor Vcb Switchgear Panel
  • Kyn61 40.5 MV 33kv Indoor Vcb Switchgear PanelKyn61 40.5 MV 33kv Indoor Vcb Switchgear Panel
  • Kyn61 40.5 MV 33kv Indoor Vcb Switchgear PanelKyn61 40.5 MV 33kv Indoor Vcb Switchgear Panel

Kyn61 40.5 MV 33kv Indoor Vcb Switchgear Panel

CONSO·CN high quality kyn61 40.5 mv 33kv indoor vcb Switchgear panel is one of the maturing product in Conso Electrical, which start to produce since 2009. Conso Electrical Science and Technology Co., Ltd. is one of the earliest manufacturer could produce 35kv Switchgear, distribution transformer and compact substation in China. Conso Electrical manufactures and supplies kyn61 40.5 mv 33kv indoor vcb Switchgear panel to Water conservancy substation in Sichuan Province, Photovoltaic substation in Papua New Guinea, and mining enterprise in Xinjiang Uygur autonomous region.

Send Inquiry

Product Description
As experts in the production of Kyn61 40.5 Mv 33kv Indoor Vcb Switchgear Panels, we extend a warm invitation to both new and longstanding customers. Join hands with us on a journey to shape an even more promising future together! Anticipate not only top-notch products but also our commitment to providing unparalleled after-sale service and ensuring your orders are delivered promptly. Let's forge ahead, building on our successful collaborations and creating a future marked by excellence and reliability!

kyn61 40.5 mv 33kv indoor vcb Switchgear panel Technical Parameter:


Rated voltage (KV): 40.5;
Power frequency withstand voltage (KV): 95 (1min);
Impulse withstand voltage (KV): 185;
Rated frequency: 50Hz;
Rated current (A): 1250/1600/2000;
Rated thermal stability current (KA 4S): 25/31.5/40;
Rated dynamic stable current (KA): 63/80;
Rated short-circuit breaking current (KA): 25/31.5/40;
Rated short-circuit making current (KA): 63/80;
Rated voltage of auxiliary circuit (V): DC 24/36/48/60/110/220, AC 110/220;
Protection level: IP3X.


kyn61 40.5 mv 33kv indoor vcb Switchgear panel Introduction:


KYN61-40.5 (Z) refers to the armored movable AC metal enclosed switchgear which is a complete indoor power distribution device with a three-phase AC flow rate of 50Hz and a rated voltage of 40.5kV. As a power plant, substation, and industrial and mining enterprise receiving and distributing electricity, it has functions such as control, protection, and detection for circuits, and can also be used in frequently operated places. CONSO·CN high quality kyn61 40.5 mv 33kv indoor vcb Switchgear panel is suitable for three-phase AC power systems with a rated voltage of 40.5kV and a rated frequency of 50Hz. kyn61 40.5 mv 33kv indoor vcb Switchgear panel is used to receive and distribute electrical energy, and to control, protect, and detect circuits. In addition to being widely used in general power systems, it can also be used in places with frequent operations.

The cabinet structure of kyn61 40.5 mv 33kv indoor vcb Switchgear panel adopts an assembled type, and the circuit breaker adopts a handcart floor structure; Equipped with a brand new composite insulated vacuum circuit breaker and with good interchangeability; The handcart frame is equipped with a screw nut pushing mechanism, which can easily move the handcart and prevent accidental operation from damaging the pushing mechanism; The interlocking between the main switch, handcart, and switch cabinet door adopts a forced mechanical locking method, meeting the "five prevention" function; All operations can be carried out with the cabinet door closed; The cable room has ample space and can connect multiple cables; Quick grounding switch for grounding and circuit short circuit; The shell protection level is IP3X, and when the handcart compartment door is open, the protection level is IP2X.


kyn61 40.5 mv 33kv indoor vcb Switchgear panel in assembling:


HXGN10-12

KYN28-12

HYXGN10-24

KYN61-40.5

kyn61 40.5 mv 33kv indoor vcb Switchgear panel in testing:



kyn61 40.5 mv 33kv indoor vcb Switchgear panel in Package:



kyn61 40.5 mv 33kv indoor vcb Switchgear panel Workshop:



kyn61 40.5 mv 33kv indoor vcb Switchgear panel in Application:
