112 Kva Industrial Power Transformer 110 To 220

To produce a reliable 112 kva industrial power transformer 110 to 220, Conso Electrical Science and Technology Co., Ltd inspects the quality of purchased raw materials, outsourced parts, and critical components before they are put into storage or production, to ensure they meet technical specifications and quality requirements. Meanwhile, in the process of making 112 kva industrial power transformer 110 to 220, inspectors will check the important quality characteristics to windings, and tanks to prevent defective products from being produced during the manufacturing process. Finally, each produced 112 kva industrial power transformer 110 to 220 must take a comprehensive inspection before it leaves, verifying that the product meets the design specifications, technical requirements, standards, and contractual agreements.

Send Inquiry

Product Description

Product Main Applications:

1.Regional and Building Power Supply

110V to 220V 112 kva power transformers are used to step down grid voltage to levels suitable for residential buildings, retail facilities, offices, and other commercial premises.

2.Industrial Equipment

110V to 220V 112 kva power transformers provide the suitable power required for the safe and reliable operation of machinery and equipment in industrial plants.

3.Transportation Systems

110V to 220V 112 kva power transformers supply power for traffic control systems, signaling equipment, and rail transit infrastructure.

4.Auxiliary Functions in Power Systems

110V to 220V 112 kva power transformers are applied in auxiliary roles, such as grounding transformers, to establish a neutral point and improve overall power system reliability.

Product Parameter:

Rated Capacity		112 kVA
Primary Voltage		220/230/240; 380/400/415; 690/800
Secondary Voltage		110V/ 120V; 220/230/240; 380/400/415
Rated Frequency		50 Hz or 60 Hz
Phase Number		Three Phase or Single Phase
Tapping Ranges		±5% or ±2*2.5%
InsulationClass	Dry type	Class F (150℃), Class H (180℃ )
	Oil immersed	Class A (105℃)
Cooling Method	Dry type	AN/AF
	Oil immersed	ONAN
Max. Working Temperature		+40℃
Min. Working Temperature		-25℃, -40℃ or -60℃
