10kva 120v To 220v Power Transformer 3 Phase

Since 2006, Conso Electrical Science and Technology Co., Ltd has manufactured 10kva 120v To 220v Power Transformer 3 Phase and other 10 kv to 35 kv power distribution transformers. During those decade years, Conso Electrical has possessed extensive experience in low voltage and medium voltage transformer design. The Conso Electrical could design a 3 phase 10kva 120v to 220v power transformer as the requirement of clients, including voltage combinations, capacity, insulation class, temperature rise, and enclosure protection rating. The technical team utilized electromagnetic simulation and thermal design optimization to ensure long term stable operation.

Send Inquiry

Product Description

A 10kva 120v To 220v Power Transformer 3 Phase is an electrical unit designed to convert utility AC voltage, to adjust voltage levels required by electrical equipment. Commonly, It is applied in industrial machinery, and power distribution systems

3 phase 10kva 120v to 220v power transformers are generally manufactured in dry type, naturally air cooled designs. The dry type low voltage power transformers offer high operational safety, easy maintenance, and reliable performance. The important technical specifications, such as input and output voltages, vector groups, insulation classes, and enclosure protection, can be customized to meet different application requirements.

With the continued development of industrial automation, intelligent manufacturing, and urban infrastructure, demand for 3 phase low voltage power transformers is steadily increasing:

1.Upgrades in industrial equipment are driving the need for highly reliable power supply solutions.

2.Renewable energy systems and smart distribution networks are placing higher requirements on efficiency and low loss performance.

3.The growth of international engineering projects is increasing demand for customized products and compliance with multiple technical standards.

Product Parameter:

Rated Capacity	10 kVA
Primary Voltage	380 V/400 V/415 V
Secondary Voltage	220 V/200 V/127 V/110 V
Voltage Tolerance	±5%
Tap Range	±2 × 2.5%
Vector Group	Dyn11 or Yyn0
Rated Frequency	50 Hz or 60 Hz
Phase Number	Three Phase
Max. Working Temperature	40℃
Min Working Temperature	-25℃; -40℃; -60℃
InsulationClass	Class F (150℃), Class H (180℃ )
Cooling Method	AN
